Pentek RFFE20-BB Iron Reducing Filter

The MAZ 10 inch and 20 inch filter cartridges are designed to provide an easy and effective method for reducing dissolved iron from water that results in an improvement of water taste. These cartridges are helping to eliminate the orange and brown stains that are often found in sinks, toilets, tubs and other plumbing fixtures. It also reduces the possible damage to pipes and water heaters.

Completely suited to drinking water applications, the MAZ cartridges should be installed on the main cold water line after the pressure tank or water meter. For best results, pre-sediment and post carbon treatment is recommended. As water flows through the cartridge the MAZ causes the iron to oxidize and drop out of the flow, holding it within its matrix to ensure no harmful chemicals are added to the water.

20" x 4.5"



The latest in carbon technology, Pentair Fibredyne stands for best of both worlds: a range of cartridges that combine activated carbon technology with depth filtration. This allows all the benefits of activated carbon with minimum pressure drop, thanks to using powdered activated carbon embedded in a polyethylene matrix. With premium chlorine, taste and odour reduction, the CFB-Plus is a versatile cartridge, with the highest sediment reduction promoting a long life and the ideal, trusted choice for residential, commercial or industrial applications.

Pentek (Pentair) 20" Big Blue High Flow Clear Housing

Available in both 10" and 20" lengths in large diameter Big Blue (BB), these extra-large housings allow for greater capacity, reducing both the number of vessels required for high flow rate applications and cartridge changeout frequency. Big Blue housings are compatible with a broad range of chemicals due to their all-polypropylene construction.

The 20" clear Big Blue version is manufactured with a polypropylene head and  polycarbonate sump and is only available with 1" NPT port.

Pentair Big Blue® Clear housings come with FDA grade Buna-N o-rings.

NOTE: Not Supplied with Fixing Bracket or Spanner. Please add these below if required.

Pentek EPM-20BB Wide Diameter Carbon Block

The EPM range is aimed at applications where frequent changeout is required, typically batch processes and where a lower capacity cartridge suits regular routine changeouts. Extruded from bituminous, acid-washed activated powder with a medium mesh structure, the high porosity design and 10 micron filtration prevent plugging prematurely and eliminate the need for pre-filtration. EPM cartridges are NSF 42 certified and are manufactured entirely from FDA compliant materials making them an ideal choice for a wide range of applications including food service.

Pentek EP-20BB 20" Wide Diameter Carbon Block

An extension to the EPM range is the NSF 42 certified EP, offering 100% greater removal capacity for only a 10% average increase in cost.

EP Series carbon briquette cartridges are manufactured using a patented process that yields a cartridge with a nominal 5-micron filtration rating, high dirt-holding tolerance. A high porosity design helps prevent the cartridge from plugging before its adsorption capacity is exhausted, maximizing the utilization of the carbon while maintaining low pressure drop.

These cartridges are protected by Endurawrap®, a uniquely formulated polyolefin bilaminate pre-filter, designed to significantly increase the useful life of the cartridge by trapping sediment that typically plugs carbon block cartridges.

Available in 10" (9 3/4") and 20" sizes.
Please call us for volume discounts on these or any other filters

Pentek CBC-20BB High Flow Big Blue Carbon Block 20 inch 0.5 Micron Sediment Filter

Pentair Pentek CBC Series Cartridges are highly effective at reducing unwanted bad taste & odor and chlorine taste & odor and other contaminants from potable drinking water.

CBC Series Cartridges are an ideal choice for a wide range of residential, food service, commercial and industrial applications. They also make excellent polishing filters or pre-filters in applications requiring fine filtration and high capacity.

Features and Benefits

• Reduces particles as small as 0.5 micron in size by mechanical means
• Premium high capacity bad taste & odor and chlorine taste & odor reduction
• Enhanced dirt-holding capacity

Certifications

• The CBC-10, CBC-20, CBC-BB and CBC-20BB are Tested and Certified by NSF International to NSF/ANSI Standard 42 for material requirements only.

Pentek FloPlus 10" Carbon Filter

The FloPlus from Pentair uses Fibredyne technology to significantly enhance cyst, chlorine and sediment reduction.

The FloPlus™ is an NSF 53 certified cyst reduction cartridge, that functions like a nominal 10 micron cartridge. Handling extremely high flow rates (in excess of 95 lpm) with no detriment to the water quality, and delivering outstanding chlorine, taste and odour, and 99.95% cyst reduction, the FloPlus in their standard or large diameter configurations combine the advantages of a depth filter with one of the greatest life capacity, cyst-capable carbons.



Available in 10" (9 3/4") and 20"" sizes.

Carbon in a format of granular activated carbon(GAC) has the most flexible properties. For watertreatment, GAC combines well with other mediasuch as phosphate, resins and sediment traps forspecific contaminant targeting.

Using a clean, acid-washed bituminous carbon with a large mesh size, this granularrange is primarily a chlorine, taste and odour reduction cartridge with the advantage ofa coarse 20 micron pre and post-filter pad to retain carbon fines that is not susceptibleto blockage if high particulate is present.

Will fit most 20"BB Pentek style housings.

The WS series of water softening cartridges are an effective and efficient solution for point-of-use applications that benefit from ease of installation and changeouts.

Designed to trap and reduce hardness and scale deposits the WS range is an excellent solution for exact point-of-use applications. These cation exchange softening cartridges use a bed of FDA compliant insoluble resin beads to reduce hardness by replacing calcium ions for sodium ones, thereby eliminating the hardness and scale deposit buildups.

Available in three different capacities and flow rates, the convenient and space-saving design of the WS series means softened water can be provided easily and cost effectively at the exact point of need.

This 10" cartridge is designed to fit into any standard 10" housing.
